Horizon S3 U-500 panoramic camera |
|
|
Horizon S3 U-500 panoramic camera
Description:
Horizon-S3 U-500 is a special camera with a rotating
non-intercheangable built-in lensintended for taking various panorama pictures:
landscapes, interiors, sports scenes, architecture, reportings, fashion, tourism,
etc., both by the amateur and professional photographers.
It can be used to take various pictures on black-and-white
and color 35mm films.
Advantages of the camera:
- the lens with high resolution rotates during taking
within the pan angle and ensures an excellent quality of image across the
whole frame field. It takes place at the expense of absence of an inevitable
optical distorsion which may be possible during the analogous taking when
using wide angle lenses;
- to have the increased exposure time range from 1/2
up to 1/500sec, what may be better for a photographer?! Durable exposure times
allow shooting under the conditions of low illumination and at night. One
may have an interesting picture taking a moving object by day;
- the optical viewfinder gives the possibility to define
accurately the limits of the taken object. The correct position of he panoramic
camera is controlled by means of the air bubble seen in the field of view
of the viewfinder. Would you like to let your imagination run away? Shift
the bubble up or down you will have an unusual special effect;
- the body of the camera is light, it is strongly built
and highly ergonomic. It was designed in such a way that one could easily
hold it under the various taking conditions.
Horizon S3 U-500 panoramic camera Kit
The basic Horizon S3 U-500 camera kit includes:
- Horizon S3 U-500 Panoramic Camera
- Handle
- Nylon pouch case
- UV, yellow-green, and neutral density filters for
the lens
- Neck strap
- Case
- Packing box
- Manual
Horizon S3 U-500 panoramic camera Specifications:
| Built-in
lens: |
The
MC 28mm f/2.8 lens with the improved optical characteristics |
| Film
type: |
perforated
35 mm |
| Number
of frames: |
22
(with the standard film length in a cassette of 1.65m) |
Angular
Field of Lens:
horisontal:
vertical: |
120
45 |
| Shutter
speeds, s: |
1/2, 1/4, 1/8, 1/60, 1/125, 1/250, 1/500 |
Depth
of Lens Field:
n=2.8
n=4.0
n=5.6
n=8.0
n=11.0
n=16.0 |
5.5
3.9
2.9
2.0
1.5
1.0 |
| Other Features: |
- the winding lever
- the built-in viewing device
- the optical level in the field of view of the viewer, the level accuracy
is 5
- tripod bush thread 1/4" |
| Dimensions,
mm: |
117.5x146x73 |
| Weight,
kg: |
0.75 |
|
