Teleconverter MC TKL-2
Description:
Teleconverter MC TKL-2 can be attached directly to cameras with the
M42 mount and to other SLR cameras with the appropriate adapters listed on this
site under "Adapters".
Use of the TKL-2 teleconverter reduces the effective aperture by two
full stops and increases the focal length by a factor of 2. With the teleconverter
the 300mm f 4.5 Rubinar the effective focal length is 600mm and the aperture
opening becomes f6.3, with the 500mm f5.6 and the teleconveter the focal length
becomes 1000mm and the aperture becomes f8. With the 1000mm f10 the effective
focal length becomes 2000mm and the effective aperture is f22." With the new
Digital SLR cameras using reduced size sensors an additional magnification of
1.5x becomes standard. This however does not change the effective aperture.
These lenses are not fitted with iris diaphragms so the calculated numerical
aperture listed above must be used with exposure devices. Most Digital SLR cameras
can be used on aperture priority for automatic exposure, on most the aperture
automatically becomes "00" and exposure times are adjusted by the cameras auto
exposure system".
Teleconverter MC TKL-2 Specifications:
| Maximum Magnification |
2x |
| Working distance, mm |
45,5 |
| Type of mount |
M42 x 1 |
| Overall dimensions, mm |
Diam. 55x40 |
| Mass (less carrying case), kg |
0,125 |
Here is a picture of the Teleconverter TKL-2 attached to Rubinar 10/1000
Macro Telephoto lens of Zenit 412 DX camera.
|
